Nominal size |
0.6 |
0.8 |
1.0 |
1.2 |
1.6 |
2.0 |
2.5 |
d1(mm) |
0.5 |
0.7 |
0.9 |
1.0 |
1.4 |
1.8 |
2.3 |
b (mm) |
2.0 |
2.4 |
3.0 |
3.0 |
3.2 |
4.0 |
5.0 |
c (mm) |
0.9 |
1.2 |
1.6 |
1.7 |
2.4 |
3.2 |
4.0 |
L (mm) |
4-12 |
5-16 |
6-20 |
8-25 |
8-32 |
10-40 |
12-50 |
Nominal size |
3.2 |
4.0 |
5.0 |
6.3 |
8.0 |
10.0 |
13.0 |
16.0 |
20.0 |
d1(mm) |
2.9 |
3.7 |
4.6 |
5.9 |
7.5 |
9.5 |
12.4 |
15.4 |
19.3 |
b (mm) |
6.4 |
8.0 |
10.0 |
12.6 |
16.0 |
20.0 |
26.0 |
32.0 |
40.0 |
c (mm) |
5.1 |
6.5 |
8.0 |
10.3 |
13.1 |
16.6 |
21.7 |
27.0 |
33.8 |
L (mm) |
18-80 |
20-125 |
20-125 |
28-140 |
36-140 |
56-200 |
90-250 |
125-280 |
160-280 |
|
|
| |
|
|
